Hale Pet Door Replacement Flap Kit for Pet Doors
Hale Pet Door Replacement Flap Kit for Pet Doors
SKU: HL-RPFL00B
Estimated Shipping Widget will be displayed here! (with custom color)
Orders over $499 qualify for free shipping.
Couldn't load pickup availability
Pet's Choice Guarantee
Replacement Flap Kits for Pet Doors
Please note: Hale flaps are designed for each model individually and the interior and exterior flaps are different. While they are the same size, the strikes and weather stripping are arranged in different locations to match up with the magnets in the door frame. Please verify whether you need an interior flap, exterior flap, or both flaps before ordering.
All replacement flap kits include, at no additional charge to you:
- Replacement nylon weather stripping
- Magnets
- Drill bit
- Screws
- Pet Door Flap(s)
If you aren't sure of your Hale Pet Door size, you can measure the pet door frame. This is the outside TIP TO TIP measurement both horizontally and vertically. After measuring, you can find the correct size pet door below using the following conversion table:
| Door Frame Tip to Tip | Order Flap Size | Flap Opening |
|---|---|---|
| 8 3/8" x 10 3/8" | Small | 5 1/2" x 7 1/2" |
| 9 9/16" x 12 9/16" | Small Medium | 6 1/2" x 9 1/2" |
| 9 9/16" x 15 3/8" | Tall Small Medium | 6 1/2" x 12 1/2" |
| 11 9/16" x 15 3/8" | Medium | 8 1/2" x 12 1/2" |
| 11 9/16" x 19 1/16" | Tall Medium | 8 1/2" x 16" |
| 14 1/16" x 19 1/16" | Large | 11" x 16" |
| 14 1/16" x 22 9/16" | Tall Large | 11" x 19 1/2" |
| 14 1/16" x 26 9/16" | Tall Large Plus | 11" x 23 1/2" |
| 14 1/16" x 30 9/16" | Extra Tall Large | 11" x 27 1/2" |
| 17 1/16" x 22 9/16" | Extra Large | 14" x 19 1/2" |
| 17 1/16" x 26 9/16" | Extra Large Plus | 14" x 23 1/2" |
| 18 9/16" x 30 9/16" | Giant | 15 1/2" x 27 1/2" |
Note: when ordering, please indicate whether this flap is for the interior, exterior, or if you need both.
